いまさらながら、Hyperledger Fabric v1.1.0を構築してみた (サンプル実行編)

さて、いよいよ Hyperledger Fabric のサンプルである、First Networkを実行します。

サンプル実行までの準備は、以下のブログを参照ください。

BYFNのコマンド確認

fabric-sampleの中にあるfirst-sampleに移動し、byfn.shを実行してみます。

cd ./fabric-sample/first-network
byfn.sh

Usage:
  byfn.sh up|down|restart|generate|upgrade [-c <channel name>] [-t <timeout>] [-d <delay>] [-f <docker-compose-file>] [-s <dbtype>] [-i <imagetag>]
  byfn.sh -h|--help (print this message)
    <mode> - one of 'up', 'down', 'restart' or 'generate'
      - 'up' - bring up the network with docker-compose up
      - 'down' - clear the network with docker-compose down
      - 'restart' - restart the network
      - 'generate' - generate required certificates and genesis block
      - 'upgrade'  - upgrade the network from v1.0.x to v1.1
    -c <channel name> - channel name to use (defaults to "mychannel")
    -t <timeout> - CLI timeout duration in seconds (defaults to 10)
    -d <delay> - delay duration in seconds (defaults to 3)
    -f <docker-compose-file> - specify which docker-compose file use (defaults to docker-compose-cli.yaml)
    -s <dbtype> - the database backend to use: goleveldb (default) or couchdb
    -l <language> - the chaincode language: golang (default) or node
    -i <imagetag> - the tag to be used to launch the network (defaults to "latest")

Typically, one would first generate the required certificates and
genesis block, then bring up the network. e.g.:

    byfn.sh generate -c mychannel
    byfn.sh up -c mychannel -s couchdb
        byfn.sh up -c mychannel -s couchdb -i 1.1.0-alpha
    byfn.sh up -l node
    byfn.sh down -c mychannel
        byfn.sh upgrade -c mychannel

Taking all defaults:
    byfn.sh generate
    byfn.sh up
    byfn.sh down

ずらずらずらっと、コマンドの使い方が表示されますが 最後の方に書いてある”Taking all defaults"、つまり全てデフォルトで実行したいと思います。

BlockchainのGenerate

早速、Blockchainをgenerateしてみましょう。
実行すると、「mychannelを作るけど、続けますか?」と聞かれるので「y」を入力します。

Generating certs and genesis block for with channel 'mychannel' and CLI timeout of '10' seconds and CLI delay of '3' seconds
Continue? [Y/n] y
proceeding ...

../bin/cryptogen
##########################################################
##### Generate certificates using cryptogen tool #########
##########################################################
+ cryptogen generate --config=./crypto-config.yaml
org1.example.com
org2.example.com
+ res=0
+ set +x

../bin/configtxgen
##########################################################
#########  Generating Orderer Genesis block ##############
##########################################################
+ configtxgen -profile TwoOrgsOrdererGenesis -outputBlock ./channel-artifacts/genesis.block
2018-07-15 06:27:34.334 JST [common/tools/configtxgen] main -> INFO 001 Loading configuration
2018-07-15 06:27:34.378 JST [msp] getMspConfig -> INFO 002 Loading NodeOUs
2018-07-15 06:27:34.380 JST [msp] getMspConfig -> INFO 003 Loading NodeOUs
2018-07-15 06:27:34.380 JST [common/tools/configtxgen] doOutputBlock -> INFO 004 Generating genesis block
2018-07-15 06:27:34.383 JST [common/tools/configtxgen] doOutputBlock -> INFO 005 Writing genesis block
+ res=0
+ set +x

#################################################################
### Generating channel configuration transaction 'channel.tx' ###
#################################################################
+ configtxgen -profile TwoOrgsChannel -outputCreateChannelTx ./channel-artifacts/channel.tx -channelID mychannel
2018-07-15 06:27:34.434 JST [common/tools/configtxgen] main -> INFO 001 Loading configuration
2018-07-15 06:27:34.449 JST [common/tools/configtxgen] doOutputChannelCreateTx -> INFO 002 Generating new channel configtx
2018-07-15 06:27:34.450 JST [msp] getMspConfig -> INFO 003 Loading NodeOUs
2018-07-15 06:27:34.451 JST [msp] getMspConfig -> INFO 004 Loading NodeOUs
2018-07-15 06:27:34.486 JST [common/tools/configtxgen] doOutputChannelCreateTx -> INFO 005 Writing new channel tx
+ res=0
+ set +x

#################################################################
#######    Generating anchor peer update for Org1MSP   ##########
#################################################################
+ configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/Org1MSPanchors.tx -channelID mychannel -asOrg Org1MSP
2018-07-15 06:27:34.516 JST [common/tools/configtxgen] main -> INFO 001 Loading configuration
2018-07-15 06:27:34.528 JST [common/tools/configtxgen] doOutputAnchorPeersUpdate -> INFO 002 Generating anchor peer update
2018-07-15 06:27:34.529 JST [common/tools/configtxgen] doOutputAnchorPeersUpdate -> INFO 003 Writing anchor peer update
+ res=0
+ set +x

#################################################################
#######    Generating anchor peer update for Org2MSP   ##########
#################################################################
+ configtxgen -profile TwoOrgsChannel -outputAnchorPeersUpdate ./channel-artifacts/Org2MSPanchors.tx -channelID mychannel -asOrg Org2MSP
2018-07-15 06:27:34.558 JST [common/tools/configtxgen] main -> INFO 001 Loading configuration
2018-07-15 06:27:34.575 JST [common/tools/configtxgen] doOutputAnchorPeersUpdate -> INFO 002 Generating anchor peer update
2018-07-15 06:27:34.575 JST [common/tools/configtxgen] doOutputAnchorPeersUpdate -> INFO 003 Writing anchor peer update
+ res=0
+ set +x

Blockchainの起動

generateが成功したので、Fabricを開始しましょう 開始すると、「mychannelを作るけど、続けますか?」と聞かれるので「y」を入力します。

この操作は実行が完了するまで少し時間がかかります。

 ./byfn.sh up
Starting with channel 'mychannel' and CLI timeout of '10' seconds and CLI delay of '3' seconds
Continue? [Y/n] y
proceeding ...
2018-07-14 21:35:38.561 UTC [main] main -> INFO 001 Exiting.....
LOCAL_VERSION=1.1.0
DOCKER_IMAGE_VERSION=1.1.0
Creating network "net_byfn" with the default driver
Creating volume "net_orderer.example.com" with default driver
Creating volume "net_peer0.org1.example.com" with default driver
Creating volume "net_peer1.org1.example.com" with default driver
Creating volume "net_peer0.org2.example.com" with default driver
Creating volume "net_peer1.org2.example.com" with default driver
Creating orderer.example.com    ... done
Creating peer1.org1.example.com ... done
Creating peer0.org1.example.com ... done
Creating peer0.org2.example.com ... done
Creating peer1.org2.example.com ... done
Creating cli                    ... done

 ____    _____      _      ____    _____
/ ___|  |_   _|    / \    |  _ \  |_   _|
\___ \    | |     / _ \   | |_) |   | |
 ___) |   | |    / ___ \  |  _ <    | |
|____/    |_|   /_/   \_\ |_| \_\   |_|

Build your first network (BYFN) end-to-end test

Channel name : mychannel
Creating channel...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
+ peer channel create -o orderer.example.com:7050 -c mychannel -f ./channel-artifacts/channel.tx --tls true --cafile /opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem
+ res=0
+ set +x
2018-07-14 21:35:49.372 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:35:49.475 UTC [channelCmd] InitCmdFactory -> INFO 002 Endorser and orderer connections initialized
2018-07-14 21:35:49.685 UTC [main] main -> INFO 003 Exiting.....
===================== Channel "mychannel" is created successfully =====================

Having all peers join the channel...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
+ peer channel join -b mychannel.block
+ res=0
+ set +x
2018-07-14 21:35:49.843 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:35:50.012 UTC [channelCmd] executeJoin -> INFO 002 Successfully submitted proposal to join channel
2018-07-14 21:35:50.013 UTC [main] main -> INFO 003 Exiting.....
===================== peer0.org1 joined on the channel "mychannel" =====================

CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer1.org1.example.com:7051
+ peer channel join -b mychannel.block
+ res=0
+ set +x
2018-07-14 21:35:53.181 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:35:53.333 UTC [channelCmd] executeJoin -> INFO 002 Successfully submitted proposal to join channel
2018-07-14 21:35:53.333 UTC [main] main -> INFO 003 Exiting.....
===================== peer1.org1 joined on the channel "mychannel" =====================

CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org2.example.com:7051
+ peer channel join -b mychannel.block
+ res=0
+ set +x
2018-07-14 21:35:56.546 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:35:56.680 UTC [channelCmd] executeJoin -> INFO 002 Successfully submitted proposal to join channel
2018-07-14 21:35:56.680 UTC [main] main -> INFO 003 Exiting.....
===================== peer0.org2 joined on the channel "mychannel" =====================

CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer1.org2.example.com:7051
+ peer channel join -b mychannel.block
+ res=0
+ set +x
2018-07-14 21:35:59.879 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:36:00.064 UTC [channelCmd] executeJoin -> INFO 002 Successfully submitted proposal to join channel
2018-07-14 21:36:00.064 UTC [main] main -> INFO 003 Exiting.....
===================== peer1.org2 joined on the channel "mychannel" =====================

Updating anchor peers for org1...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
+ peer channel update -o orderer.example.com:7050 -c mychannel -f ./channel-artifacts/Org1MSPanchors.tx --tls true --cafile /opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem
+ res=0
+ set +x
2018-07-14 21:36:03.359 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:36:03.415 UTC [channelCmd] update -> INFO 002 Successfully submitted channel update
2018-07-14 21:36:03.415 UTC [main] main -> INFO 003 Exiting.....
===================== Anchor peers for org "Org1MSP" on "mychannel" is updated successfully =====================

Updating anchor peers for org2...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org2.example.com:7051
+ peer channel update -o orderer.example.com:7050 -c mychannel -f ./channel-artifacts/Org2MSPanchors.tx --tls true --cafile /opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem
+ res=0
+ set +x
2018-07-14 21:36:06.681 UTC [channelCmd] InitCmdFactory -> INFO 001 Endorser and orderer connections initialized
2018-07-14 21:36:06.720 UTC [channelCmd] update -> INFO 002 Successfully submitted channel update
2018-07-14 21:36:06.721 UTC [main] main -> INFO 003 Exiting.....
===================== Anchor peers for org "Org2MSP" on "mychannel" is updated successfully =====================

Installing chaincode on peer0.org1...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
+ peer chaincode install -n mycc -v 1.0 -l golang -p github.com/chaincode/chaincode_example02/go/
+ res=0
+ set +x
2018-07-14 21:36:09.932 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:36:09.932 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
2018-07-14 21:36:12.419 UTC [main] main -> INFO 003 Exiting.....
===================== Chaincode is installed on peer0.org1 =====================

Install chaincode on peer0.org2...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org2.example.com:7051
+ peer chaincode install -n mycc -v 1.0 -l golang -p github.com/chaincode/chaincode_example02/go/
+ res=0
+ set +x
2018-07-14 21:36:12.663 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:36:12.663 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
2018-07-14 21:36:13.111 UTC [main] main -> INFO 003 Exiting.....
===================== Chaincode is installed on peer0.org2 =====================

Instantiating chaincode on peer0.org2...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org2.example.com:7051
+ peer chaincode instantiate -o orderer.example.com:7050 --tls true --cafile /opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem -C mychannel -n mycc -l golang -v 1.0 -c '{"Args":["init","a","100","b","200"]}' -P 'OR  ('\''Org1MSP.peer'\'','\''Org2MSP.peer'\'')'
+ res=0
+ set +x
2018-07-14 21:36:13.460 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:36:13.460 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
2018-07-14 21:37:02.525 UTC [main] main -> INFO 003 Exiting.....
===================== Chaincode Instantiation on peer0.org2 on channel 'mychannel' is successful =====================

Querying chaincode on peer0.org1...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
===================== Querying on peer0.org1 on channel 'mychannel'... =====================
Attempting to Query peer0.org1 ...3 secs
+ peer chaincode query -C mychannel -n mycc -c '{"Args":["query","a"]}'
+ res=0
+ set +x

2018-07-14 21:37:05.814 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:37:05.814 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
Query Result: 100
2018-07-14 21:37:34.914 UTC [main] main -> INFO 003 Exiting.....
===================== Query on peer0.org1 on channel 'mychannel' is successful =====================
Sending invoke transaction on peer0.org1...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org1MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/users/Admin@org1.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer0.org1.example.com:7051
+ peer chaincode invoke -o orderer.example.com:7050 --tls true --cafile /opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/ordererOrganizations/example.com/orderers/orderer.example.com/msp/tlscacerts/tlsca.example.com-cert.pem -C mychannel -n mycc -c '{"Args":["invoke","a","b","10"]}'
+ res=0
+ set +x
2018-07-14 21:37:35.139 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:37:35.139 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
2018-07-14 21:37:35.160 UTC [chaincodeCmd] chaincodeInvokeOrQuery -> INFO 003 Chaincode invoke successful. result: status:200
2018-07-14 21:37:35.160 UTC [main] main -> INFO 004 Exiting.....
===================== Invoke transaction on peer0.org1 on channel 'mychannel' is successful =====================

Installing chaincode on peer1.org2...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer1.org2.example.com:7051
+ peer chaincode install -n mycc -v 1.0 -l golang -p github.com/chaincode/chaincode_example02/go/
+ res=0
+ set +x
2018-07-14 21:37:35.418 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:37:35.418 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
2018-07-14 21:37:35.763 UTC [main] main -> INFO 003 Exiting.....
===================== Chaincode is installed on peer1.org2 =====================

Querying chaincode on peer1.org2...
CORE_PEER_TLS_ROOTCERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/peers/peer0.org2.example.com/tls/ca.crt
CORE_PEER_TLS_KEY_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.key
CORE_PEER_LOCALMSPID=Org2MSP
CORE_VM_ENDPOINT=unix:///host/var/run/docker.sock
CORE_PEER_TLS_CERT_FILE=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org1.example.com/peers/peer0.org1.example.com/tls/server.crt
CORE_PEER_TLS_ENABLED=true
CORE_PEER_MSPCONFIGPATH=/opt/gopath/src/github.com/hyperledger/fabric/peer/crypto/peerOrganizations/org2.example.com/users/Admin@org2.example.com/msp
CORE_PEER_ID=cli
CORE_LOGGING_LEVEL=INFO
CORE_PEER_ADDRESS=peer1.org2.example.com:7051
===================== Querying on peer1.org2 on channel 'mychannel'... =====================
Attempting to Query peer1.org2 ...3 secs
+ peer chaincode query -C mychannel -n mycc -c '{"Args":["query","a"]}'
+ res=0
+ set +x

2018-07-14 21:37:38.943 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 001 Using default escc
2018-07-14 21:37:38.943 UTC [chaincodeCmd] checkChaincodeCmdParams -> INFO 002 Using default vscc
Query Result: 90
2018-07-14 21:38:05.345 UTC [main] main -> INFO 003 Exiting.....
===================== Query on peer1.org2 on channel 'mychannel' is successful =====================

========= All GOOD, BYFN execution completed ===========


 _____   _   _   ____
| ____| | \ | | |  _ \
|  _|   |  \| | | | | |
| |___  | |\  | | |_| |
|_____| |_| \_| |____/

いまさらながら、Hyperledger Fabric v1.1.0を構築してみた (サンプル実行の準備編)

環境構築編で環境が準備できたので、次はDocker イメージなどをインストールして、サンプル実行までの準備を行います。

環境構築が未だの方はこちらを参照ください。 fedorax.hatenablog.com

Fabric Sampleのダウンロード

githubからソース一式をcloneします。
version指定を忘れずに!

git clone https://github.com/hyperledger/fabric-samples.git
git checkout release-1.1

Fabric Platform イメージの取得

次に、Fabricを実行するためのplatformのイメージを取得します。

curl -sSL https://goo.gl/6wtTN5 | bash -s 1.1.0

インストールが終わると、こんな感じで出力されます。

===> List out hyperledger docker images hyperledger/fabric-tools latest b7bfddf508bc 3 months ago 1.46GB hyperledger/fabric-tools x86_64-1.1.0 b7bfddf508bc 3 months ago 1.46GB hyperledger/fabric-orderer latest ce0c810df36a 3 months ago 180MB hyperledger/fabric-orderer x86_64-1.1.0 ce0c810df36a 3 months ago 180MB hyperledger/fabric-peer latest b023f9be0771 3 months ago 187MB hyperledger/fabric-peer x86_64-1.1.0 b023f9be0771 3 months ago 187MB hyperledger/fabric-ccenv latest c8b4909d8d46 3 months ago 1.39GB hyperledger/fabric-ccenv x86_64-1.1.0 c8b4909d8d46 3 months ago 1.39GB

なんか、もっとコマンドを実行して準備するのかと思っていたけど、
1コマンドでサンプル実行までの準備ができてしまいました。

いまさらながら、Hyperledger Fabric v1.1.0を構築してみた (環境構築編)

今更ながら、Hyperledger Fabric v1.1.0の環境を構築しました。

環境準備

公式のガイドを見ながら、自分の環境を確認して、不足しているところを対応しました。

http://hyperledger-fabric.readthedocs.io/en/release-1.1/prereqs.html

構築した時の環境はこんな感じ。

  • Mac OSX

  • Docker > v 17.06.2-ce

    • 以下のコマンドで確認

      docker —version

  • Docker Compose > v 1.14.0
    • 以下のコマンドで確認

      docker-compose —version

  • 環境変数の設定
    • ~/.bashrcにGOPATHを設定
      (注意:スペース不要)

      GOPATH=/opt/go

    • PATHにgoがあるbinフォルダを設定
      (注意:スペース不要)

      PATH=$PATH:$GOPATH/bin

  • Go > v 1.9.x
    • 以下のコマンドで確認
      (v 1.8以下はサポート外)

      go version

以上。


この後、Fabric SDKを使う予定があるので、Node.jsのバージョンも確認

  • Node.js > v 8.9.x
    • 以下のコマンドで確認
      (v 9.x以降は現時点でサポート外)

      node —version

Ubuntu ユーザーの方はPython 2.7が必要とのこと。

  • python v 2.7
    • 以下のコマンドで確認

      python -- version

Spring Tool Suite(Eclipse) が起動しない「Java was started but returned exit code=13」

Spring Frameworkを独学しようと、STS(Spring Tool Suite)をダウンロードして起動したら下記のエラーが f:id:fedorax:20171211094045p:plain

Javaのバージョンチェック

Java Versionが【1.8】だったから問題なし。

>java -version

f:id:fedorax:20171211094226p:plain

Stackoverで聞いてみる。

Javaのバージョンに問題が無かったので、人柱が集うStackoverに聞いてみるとEclipseで既に問題に遭遇している記事を発見。 Spring Tool SuiteもEclipseで出来ているので、この記事に沿ってやってみる。

stackoverflow.com

STS.ini(eclipse.ini)の編集

Eclipseの設定ファイルであるSTS.iniを開き、以下の設定を追加した。 (Eclipse の場合は、eclipse.iniファイル)

-vm
C:\Program Files\Java\jdk1.8.0_<バージョン>\bin\javaw.exe

起動してみる

「ジャーン」とアラート音が、、、さらに悪化したぞ f:id:fedorax:20171211095701p:plain

とりあえずOKを押して、エラーの内容を確認すると、同やらSTSWindows 32bit向けらしい (先ほど、設定したjavawのプログラムは64bit版) f:id:fedorax:20171211100042p:plain

Spring Tool Suiteの再ダウンロード

公式サイトに行き、【See All Version】を選択
https://spring.io/tools/sts

f:id:fedorax:20171211101307p:plain

f:id:fedorax:20171211100525p:plain

Spring Tool Suite 64bit版をダウンロード

f:id:fedorax:20171211100944p:plain

Spring Tool Suiteを起動

ダウンロードしたzipを展開して、STS.exeを起動 f:id:fedorax:20171211101159p:plain

f:id:fedorax:20171211101341p:plain

無事、起動しました。

angular-cliでng serve時に自動的にブラウザを開く方法

Angularでng serveを実行した後に、いちいちブラウザを開くのが手間だったので、 ng serve実施時に自動的にブラウザを開く方法が無いか探してみました。

ng serveに-oのオプションをつけるだけ

今までのng seveコマンドに -oをつけてみます。

ng serve -o

f:id:fedorax:20171123163732p:plain

package.jsonを編集

"scripts": {
    "start": "ng serve -o"
}

これで、ひとつ無駄が省けました。

BluemixでAngular2を動作させる

こんにちは、fedoraxです。

Bluemixの環境で、Angularを動作させるための備忘録です。

1. Angularプロジェクトを作成します。

ng new <project name>

2. Angularのソースを編集します。

Coding

3. ローカルサーバで動作確認します。

ng serve

4. アップロード用にビルドします。

ng serve

5. bluemix用の定義ファイルをdistフォルダに用意します。

applications:
- name: angular-for-bluemix
  random-route: true
  memory: 64M
  buildpack: staticfile_buildpack

6. Staticfileのからファイルをdistフォルダに用意します。

f:id:fedorax:20171119202047p:plain

7. bluemixにアップロードします。

cf push
